RAM QUAD AND CREW CAB
Fits
* 3rd & 4th gen "2002-2018" 1500, 2500 & 3500
* 5th gen "2019-up" 2500 & 3500 Does NOT fit 1500s
* 2019-UP "CLASSIC" 1500, 2500 & 3500
2-12" VENTED SUB BOX
SUB SIZE: 12"
SUB HOLE SIZE: 11.15"
MOUNTING DEPTH: 7"
MAX MAGNET DIAMETER: 7.5"
INTERNAL AIR VOLUME: 1.55 FT3 PER SUB
TUNE FREQ: 35hz
1" seat lift kit is included and is required for proper fit.
12" to 10" adapter ring available if you want to use a 10" subs.
Subs with large diameter frames will require trimming of the opening by the installer.
Popular subs: No particular order
Alpine: Type S &Type R
Punch: P1, P2 & P3
Kicker: Comp, C, VR, VX & R
JL Audio: W0, W1, W3
Sundown: EV3, SA Classic
Skar Audio: IX, VD, DDX, SDR, SVR & EVL
Memphis: SR, PR & MB
